Daikin MC30YB Air Purifier

Type

• Air Purifier

Product Code

• MC30YB

Application

• Floor standing type

Casing Colour

• White

Dimensions

• Height (mm) - 450
• Width (mm) - 270
• Depth (mm) - 270
• Weight (kg) - 5.8

Applicable room area (m²)

• 23 (1), 46 (2)

CADR (m³/h)

• 180

Air purifying operation
Power input

• Turbo (kW) - 0.025
• Medium (kW) - 0.015
• Silent (kW) - 0.008

Fan
Air flow rate
Air purifying operation

• Turbo (m³/h) - 180
• Medium (m³/h) - 120
• Silent (m³/h) - 60

Dust collecting method

• Electrostatic HEPA filter

Deodorising method

• Flash streamer + Deodorising catalyst

Standard Accessories

• Electrostatic HEPA filter - 1
• Deodorising filter - 1
• Operation manual - 1
• Power cord (m) - 1.8

Power supply

• Phase - 1~
• Frequency (Hz) - 50/60
• Voltage    (V) - 220-240/220-230

Running current
Air purifying operation

• Turbo (A) - 0.13
• Medium (A) - 0.09
• Silent (A) - 0.08

Notes

• (1) - The applicable room area is appropriate for operating the unit of maximum fan speed (HH). Applicable room area indicates the space where a certain amount of dust particles can be remover in 30 minutes. (JEM 1467)
• (2) - The applicable room area is appropriate for operating the unit of maximum fan speed (HH). Applicable room area was calculated in accordance with NRCC-54013 standard using cigarette smoke CADR that was tested according to JEM1467.
• (3) - Converted to CADR standards from test values in accordance with JEM1467.
• (4) - Operating sound levels are the average of values measured at 1m away from the front, left, right and top of the unit. (These are equal to the values in an anechoic chamber)
• (5) - Electrostatic HEPA filter is attached in the unit.
• (6) - Other function : Auto-restart function.
